🔍 Product Overview

The ACS712 module is a smart, compact current sensor board capable of accurately measuring both AC and DC currents up to 20 A. Built around the Hall-effect sensor principle, it translates the magnetic field generated by current flow into an analog voltage that your microcontroller can easily read.

---

🚀 Why It’s Ideal for Your Projects

• High range & flexible usage: With a 20 A measurement capacity, you can monitor motors, power supplies, battery systems, and more — all within a compact module.

• Simple to integrate: The output is a standard analog voltage proportional to current flow, making it easy to interface with boards like Arduino, Raspberry Pi (via ADC), and similar microcontrollers.

• Precision design: Includes features like low-noise analog signal path, fast 5 µs rise time for current steps, and isolation between sensor and microcontroller.

---

📝 Key Features

• Measures current range: ±20 A (AC or DC)

• Output sensitivity and analog-voltage scaling matched for easy reading

• Built-in copper conduction path with Hall-effect sensing provides isolation and durability

• Isolation voltage: ~2.1 kV RMS between measurement side and logic side

• Compact board size—suitable for hobby, robotics, and embedded applications

---

🎯 Typical Applications

• Monitoring battery packs in DIY electric vehicles or energy storage systems

• Sensing motor current in robotics, CNC machines, or automation platforms

• Building watt meters, power usage monitors, over-current protection circuits

• Any project where you need to “see” how much current is flowing and react accordingly

---

✅ Why Choose This Module?

• It takes the guess-work out of current measurement, giving you real-time analog output that your microcontroller can act upon.

• Because it uses a Hall-effect design, it has built-in isolation and works for both AC and DC — very handy in mixed systems.

• Installation is straightforward and it plays well with existing electronics ecosystems you may already use.
